Unit：mm
9.8 Newton(N)=1 Kg=2.2 LBS
| Model No. | Stroke (A) |
Extended Length (B) |
Force Range(N) |
Remark |
| SB3-233-D8-XXXNDT | 70 | 233 | 100~1150 | |
| SB3-263-D8-XXXNDT | 90 | 263 | 100~1150 | |
| SB3-278-D8-XXXNDT | 100 | 278 | 100~1150 | |
| SB3-323-D8-XXXNDT | 125 | 323 | 100~1150 | |
| SB3-378-D8-XXXNDT | 150 | 378 | 100~1150 | |
| SB3-398-D8-XXXNDT | 160 | 398 | 100~1150 | |
| SB3-443-D8-XXXNDT | 180 | 443 | 100~1150 | |
| SB3-478-D8-XXXNDT | 200 | 478 | 100~1150 | |
| SB3-493-D8-XXXNDT | 210 | 493 | 100~1150 | |
| SB3-518-D8-XXXNDT | 220 | 518 | 100~1150 | |
| SB3-578-D8-XXXNDT | 250 | 578 | 100~1150 | |
| SB3-663-D8-XXXNDT | 280 | 663 | 100~1150 | |
| SB3-678-D8-XXXNDT | 300 | 678 | 100~1150 | |
| SB3-693-D8-XXXNDT | 300 | 693 | 100~1150 | |
| SB3-743-D8-XXXNDT | 330 | 743 | 100~1150 | |
| SB3-778-D8-XXXNDT | 350 | 778 | 100~1150 | |
| SB3-823-D8-XXXNDT | 370 | 823 | 100~1150 | |
| SB3-878-D8-XXXNDT | 400 | 878 | 100~1150 |
